EU Product - PoE+ Outdoor Waterproof Extender POE15 - Switch - 1 Gbps
Introduction
Designed for Harsh Outdoor Environment
Level 3+ EMC Protection
Keep your connection online with robust protection. Additionally featuring Polarity / Overvoltage / Short-Circuit / Automatic Voltage Regulation protection.
Works in Extreme Temperatures
Works in 70 °C (158° F) and cold (-20°C / -4° F), making it suitable for outdoor installations such as parking lots, cruise decks, national parks, and more.
High-Speed. Plug and Play.
Gigabit Speed
Provides super-fast bandwidth suitable for connecting multiple cameras, high-speed access points, speakers down the line. *Connecting mulitple clients requries additional network switch at its end.
Wall-Mount Ready
Installation is straightforward with no configuration required. Mounting screws are included in the box.
Specifications
| Network | |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3x |
| Duplex system | Full, Half |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000 |
| Cable types supported | Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e, Cat8, Cat8.1 |
| Features | |
| Wall mountable | Yes |
| Easy to install | Yes |
| Plug and Play | Yes |
| Maximum operating distance | 100 m |
| Product colour | Black |
| Pin assignment & polarity | 1/2 (-), 3/6 (+), 7/8 (-), 4/5 (+) |
| LED indicators | Activity, Link, PoE |
| International Protection (IP) code | IP67 |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3x |
| Package type | Box |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Power | |
| Output power | 30 W |
| Power consumption (max) | 2 W |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -13 - 131 °F |
| Operating temperature (T-T) | -22 - 55 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Weight & dimensions | |
| Weight | 250 g |
| Width | 185 mm |
| Depth | 45 mm |
| Height | 45 mm |
| Package weight | 307 g |
| Package depth | 76 mm |
| Package width | 152 mm |
| Package height | 54 mm |
| Packaging data | |
| Package weight | 307 g |
| Package type | Box |
| Package depth | 76 mm |
| Package width | 152 mm |
| Package height | 54 mm |
| Technical details | |
| Package width | 152 mm |
| Package height | 54 mm |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | -13 - 131 °F |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Packaging content | |
| Package type | Box |
| Indication | |
| LED indicators | Activity, Link, PoE |
