Ethernet Parallel Network Print Server 1 Port 10/100 Mbps

Introduction

The PM1115P2 Ethernet to Parallel Network Print Server lets you convert a standard parallel printer into a shared network printer over a 10/100Mbps network. Providing network printing access allows you to share a single printer among multiple network connected computers, while also avoiding the added costs and inconveniences of purchasing printers for each workstation or area.

This compact, lightweight Ethernet print server connects directly to the Centronics port on your printer, for a discreet solution that doesn't require a cable between your printer and the device - simply connect the device to the network using an RJ45 cable. The ability to position your printer anywhere on the network does away with the need for a dedicated print server PC, saving resources and avoiding performance bottlenecks.

The parallel print server can have you up and running in minutes, using either a remote web-based or Windows based installation wizard. The print server offers broad operating system compatibility and works with a wide variety of parallel printing devices for easy installation into mixed environments, and also supports Simple Network Management Protocol (SNMP) for remote monitoring.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Benefits

• Avoid the added costs of purchasing additional printers with network print sharing
• Convenient setup options with Windows or web-based configuration
• Broad compatibility for use with most parallel printers on the market

Features

• Connects directly to the Centronics port of a printer
• Compliant with IEEE 802.3, and IEEE 802.3u standards
• Compact and lightweight
• Supports SNMP for remote printer management - works with most SNMP based applications
• Easy-to-use web interface or Windows-based configuration and setup
• Support for Internet Printing Protocol(IPP), Print Job Control/Status, Email Alert, Rendezvous, DHCP Client, SNMP (v1 and 2) & HP Web JetAdmin, Windows Print Monitor Technology
• Supports 10/100Mbps Ethernet network

Specification

Connector Type(s): Centronics (36 pin) Male

RJ-45 Female

Operating Temperature: 0°C to 50°C (32°F to 122°F)

Storage Temperature: 0°C to 50°C (32°F to 122°F)

Humidity: 10~70% RH

Ports: 1

Interface: Parallel

RJ45 (10/100 Ethernet)

Industry Standards: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX

LED Indicators: Power/Status: Yellow Solid

100Mbps Link/Activity: Green Solid/Flashing

10Mbps Link/Activity: Yellow Solid/Flashing

Shipping (Package) Weight: 359 g [12.7 oz]

Maximum Data Transfer Rate: 100Mbps

Remote Management Ability: Yes

Supported Protocols: IPX

Color: Beige

Enclosure Type: Plastic

Product Length: 60 mm [2.4 in]

Product Width: 62 mm [2.4 in]

Product Height: 24 mm [0.9 in]

Product Weight: 52 g [1.8 oz]

Power Source: AC Adapter Included

Input Voltage: 100 ~ 240 AC

Input Current: 0.2 A

Output Voltage: 5 DC

Output Current: 1 A

Center Tip Polarity: Positive

Plug Type: H

OS Compatibility: Windows 2000, XP, Vista, 7, 8, 8.1, 10

System and Cable Requirements: Ethernet network cable not included

Note: OS Compatibility refers to the included software only - the Print Server itself can be used without software on any platform that supports network printing

Included in Package: Parallel Print Server

Power Adapter

Software CD

Quick Start Guide
