EU Product - USB Steckdosenadapter 1xUSB-A, 1xUSB-C, 65W weiß

Introduction

The LogiLink USB-C GaN 65W Charger is an ultra-slim charger that has been specially developed for tight spaces. Thanks to the innovative GaN technology, it is physically smaller and dissipates higher voltages than silicon-based chargers, with better heat dissipation. At just 1.4 cm thick, it is ideal for travelling and narrow sockets.

The charger offers a maximum total output power of 65 W. It has a USB-C port with Power Delivery (PD) 65 W and a USB-A port with Quick Charge (QC) 4.0. You can quickly charge a USB-A and a USB-C device at the same time. Wide compatibility including laptops, smartphones, tablets and more. Enhanced safety features such as over-current, over-voltage, over-temperature and short-circuit protection ensure extremely safe charging.

Specifications

Performance
Charger type	Indoor
Charger compatibility	Universal
Power source type	AC
Power protection features	Over current, Over voltage, Overcharge, Overheating, Short circuit
Fast charging	Yes
Fast charging technology	Power Delivery 3.0, Quick Charge 4
USB Type-C ports quantity	1
USB Power Delivery (USB PD)	Yes
Wireless charging	No
USB Power Delivery revision	3.0
USB Power Delivery up to	65 W
Number of outputs	2 outputs
Number of simultaneously connected devices (max)	2
USB Type-A ports quantity	1
Design
Product colour	White
Gallium nitride (GaN) transistors	Yes
Power
Input current	1.5 A
Maximum power	65 W
Input voltage	100 - 240 V
Input frequency	50 / 60 Hz
Maximum output voltage	20 V
Minimum output voltage	5 V
Output current (5V)	3 A
Output current (9V)	2 A
Output current (12V)	1.5 A
Port 1 output power	18 W
Port 2 output power	65 W
Output current (15V)	3 A
Output current (20V)	3.25 A
Technical details
Package type	Box
Charger type	Indoor
Charger compatibility	Universal
Power source type	AC
Power protection features	Over current, Over voltage, Overcharge, Overheating, Short circuit
AC adapter included	Yes
Manual	Yes
Weight & dimensions
Width	83 mm
Depth	47 mm
Height	52 mm
Weight	79 g
Package width	75 mm
Package depth	50 mm
Package height	95 mm
Package weight	111 g
Packaging data
Package type	Box
Package width	75 mm
Package depth	50 mm
Package height	95 mm
Package weight	111 g
Quantity per pack	1 pc(s)
Operational conditions
Operating temperature (T-T)	-10 - 40 °C
Packaging content
Manual	Yes
Quantity per pack	1 pc(s)
AC adapter included	Yes
Package type	Box
Colour
Product colour	White
Other features
Manual	Yes
Package type	Box
AC adapter included	Yes
